Built for purpose, the BS-i203G delivers rapid scanning with superior reading and image capture, extracting critical data swiftly; making it ideal for high security and data sensitive industries.
- Scan mode
- Handheld 2D Barcode Scanner
- Alarm node
- LED light alarm, Buzzer alarm
- Scan rate
- 60 frames/sec
- 300 scans/sec
- Resolution
- 1280 pixels (H) x 1024 pixels (W)
- Field of View
- 39°(H)x28°(W)
- Scan angl
- 360°(Roll)
- ±65°(Skew)
- ±65°(Pitch)
- Symbol contrast
- >20% minimum reflective difference
- Barcode density
- 4mil
- Light Source
- (Aimer) Red color LED
- (Illumination) White color LED
- Decode Ranges
- Code39(5mil): 6-26 cm
- Code39(13mil): 6-45 cm
- QR(15mil): 7-25 cm
- QR(20mil): 7-40 cm
- QR(30 mil):7-60 cm
- Barcode type
- 1D: Codabar, Code 39, Code 32 Pharmaceutical (PARAF), Interleaved 2 of 5, NEC 2 of 5, Code 93, Straight 2 of 5 Industrial, Straight 2 of 5 IATA, Matrix 2 of 5, Code 11, Code 128, GS1-128, UPC-A, UPC-E, EAN/JAN-8, EAN/JAN-13, MSI, GS1 DataBar Omnidirectional, GS1 DataBar Limited, GS1 DataBar Expanded, ChinaPost (Hong Kong 2 of 5), Korea Post.
- 2D: Codeblock A, Codeblock F, PDF417, GS1 Composite Codes, QR Code, Data Matrix, MaxiCode, Aztec, HANXIN.
- Default open
- Codabar
- Code39
- Interleaved2of5
- NEC2of5
- Code93
- Code128
- GS1-128
- UPC-A
- UPC-E0
- EAN/JAN-13
- EAN/JAN-8
- GS1-DataBar
- PDF417
- QR
- DM
- Aztec
- Voltage
- DC+5V±5%
- Operating Power
- 266mA(working)
- 130mA(standby)
- 210mA(Starting)
- Interfaces
- USB, RS 232
- USBCOM Electric Safety: En55022; 2006+A1: 2007 En55024: 1998+A1: 2001+A2: 2003
- Shock Specifications
- 2000G
- 0.7ms
- half sinus
- 3 axes
- Operating temperature
- -20°C to 60°C
- Storage Temperature
- -30°C to 70°C
- Humidity
- 5% to 95% relative humidity
- non-condensing
- ESD
- +/-8 kV contact discharge
- +/-15kV air discharge
- Drop resistance
- Designed to withstand 1.8m drops
- Dimensions (L*W*H)
- 159.99*69.38*107.61 mm
- Weight
- 129.5 g
- Material
- ABS+PC
- Color
- Black
- IP Rate
- IP54
- Ambient Light Immunity
- 0-100000 Lux
- USB cable
- 1.8m
