This lightweight scanner delivers superior performance and outstanding durability. It is an ideal solution for supermarkets, shopping malls, warehouses, and other environments.
- Processor type
- ARM32-bit
- Operating Freq
- 24.5 MHz (Internal)
- Sensor
- Linear CCD Sensor
- Scan mode
- Manual/Auto sense
- Alarm mode
- Red light alarm
- Buzzer alarm
- Scan rate
- Smart detect up to 350 scans/second
- Print contrast ratio
- 20%
- Light level
- Visible red light 632 nm LED
- Resolution
- 3mil/0.1 mm@PCS90%
- Scan depth of field
- 6mil (0.127mm) 40~190mm
- 8mil (0.2mm) 35~210mm
- 10mil (0.26mm) 30~300mm
- 13mil (0.33mm) 30~350mm
- 20mil (0.5mm) 30~400mm
- Barcode type
- Australian Post
- Aztec
- BPO
- Canada Post
- Codabar
- Codablock
- Code 11
- Code 39
- Code 93
- code 128/EAN 128
- Dutch Post
- EAN
- UCC Composite
- Interleaved 2 of 5
- Japan Post
- UPC/EAN
- Voltage
- DC+5V±5%
- Operating current
- 170mA (working)
- 50mA (standby)
- 150mA (operating)
- ESD
- 5,000 Lux max
- Interfaces
- USB
- RS 232
- USBCOM
- Light source
- 40,000 hours
- MTBF (Calculated)
- 80,000 hours
- Operating temperature
- -10°C to 50°C
- Storage Temperature
- -20°C to 60°C
- Humidity
- 20% to 95% (Non-condensing)
- Drop Durability
- Designed to withstand 1.8m drops
- Dimensions (LxWxH)
- 95mm *62mm * 168mm
- Gross weight
- 175g
- Material
- PC
- Color
- Black
