LP 45 a saltwart product that stands out in the printing industry. It is the perfect blend of engineering and design that delivers top notch perforamance all around. And is the right choice for dynamic and fast paced industries likes Manufacturing, Textile, Garments, Logistics, Retail, etc., in printing their MAP packing, barcode packing, labels, stickers, tags, cards and more.
- Resolution 203 DPI
- Printing Method Direct Thermal & Thermal Transfer
- Max. Print Width 104 mm
- Max. Print Speed 125 mm/s
- CPU 32-bit RISC microprocessor
- Memory 8MB FLASH RAM, 64MB SDRAM
- Detection THP temp, position, paper mark, ribbon
- Barcode Support 1D: Code 39, UPC, EAN, Code 128, etc. ,
- 2D: QR Code, PDF417, Maxicode, etc.
- Font Support ASD smooth fonts, Courier fonts, user-defined fonts
- Graphics Supports HEX, PCX, BMP, IMG formats
- Paper Type Continuous, label, marked, perforated paper
- Max. Paper Roll O/D 127 mm
- Max. Ribbon Length 300 m
- Interface RS-232 Serial, Parallel, USB
- Power Supply AC 110-240V, 50/60Hz; DC 24V output
- Operating Temp. +5°C to 45°C, 20%-90% humidity
- Storage Temp. -40°C to 60°C, 20%-93% humidity
- Dimensions 300mm (L) × 252mm (W) × 190mm (H)
- Weight 3.5 kg
- Reliability 30 km print life or 12 months
- 203 DPI
- Printing Method
- Thermal/Thermal transfer
- Max. Print width
- 104 mm
- Max. Print speed
- 125 mm/s
- CPU
- 32 bit RISC micro-processor
- Memory
- 8 MB FLASH RAM I 64 MB SDRAM
- THP temperature detection
- Thermistor
- THP position detection
- Micro-switch
- Paper mark detection
- Optical sensor
- Ribbon detection
- Optical sensor
- Interface
- Standard configuration: RS-232 Serial, CENTRONICS Parallel, USB
- Driver
- Windows driver (98/2000/XP/Win 7/Win 8 [32-bit, 64-bit])
- Barcode
- 1D barcode Code 3 of 9, UPCA, UPCE, Interleaved 2 of 5, code 128, EAN13, EAN8, HBIC (39 code with checkout)
- Fonts
- Coda bar, industry CODE 25, Checksum & shipping bearer bars
- Graphics
- UPC2, UPC5, Code 93, POSTNET 25 (China), UCC/EAN, Matrix 25, POSTNET code, etc.
- 2D barcode
- PDF417, MAXICODE, OR code etc.
- Common single-byte font
- FONTO to FONTS, 6 kinds of ASD smooth font, 8 kinds of Courier font
- Self-defined font
- Users can define the font and download to FLASH or SDRAM
- Rotation print
- (0°, 90°, 180°, 270°)
- Graphics
- Binary plain graphics, HEX, PCX, BMP and IMG graphics can be downloaded to FLASH/RAM
- Paper type
- Continuous paper, label paper, marked paper, perforated paper
- Paper rolls 0/D (Max)
- 127 mm, ID 25mm, width (Max): 118 mm
- Ribbon length (Max)
- 300 m, OD 25 mm
- Input
- AC 110-240 V, 50/60 Hz
- Output
- DC 24 V, 1.5A & DC 24 V, 2.5 A
- Operation environment
- +5-45°, 20%-90% (40°C)
- Storage environment
- -40-60°, 20%-93% (40°C)
- Overall size
- 300 mm (L) x252 mm (W) x190 mm (H)
- Weight
- About 3.5 Kg
- a. TPH: 30 Km or 12 Months from delivery) which comes first
- b. Platen: 50 Km (Service part)
